Al Summan Metals, a leading manufacturer and supplier based in Dubai, UAE, focuses on premium Hastelloy Bright Bars designed for outstanding corrosion resistance, strength, and an impeccable surface finish. These bright bars are carefully engineered to perform in highly aggressive chemical and high-temperature environments, making them ideal for use in chemical processing, petrochemicals, marine, and aerospace industries. Al Summan Metals is dedicated to strict quality control, guaranteeing dimensional accuracy and compliance with international standards, which produces Hastelloy Bright Bars that deliver durability, mechanical strength, and enduring reliability for challenging industrial applications.
Hastelloy Bright Bars consist primarily of nickel, molybdenum, and chromium, with small quantities of iron, cobalt, and tungsten. This distinctive blend of alloys gives them exceptional resistance to oxidation, pitting, and crevice corrosion in harsh chemical settings. From a mechanical standpoint, these bars offer a tensile strength of around 690 MPa and a yield strength of about 283 MPa, coupled with notable ductility, toughness, and thermal stability. Their polished surface not only appears attractive but also eases machining and improves surface quality.
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
|---|---|---|---|---|---|---|---|---|---|---|
| C276 | 0.010 max | 1.00 max | 0.08 max | 0.03 max | 2.50 max | 50.99 min* | 14.50 – 16.50 | 4.00 – 7.00 | 15.00 – 17.00 | 0.04 max |
| C22 | 0.010 max | 0.50 max | 0.08 max | 0.02 max | 2.50 max | 50.015 min* | 20.00 – 22.50 | 2.00 – 6.00 | 12.50 – 14.50 | 0.02 max |
| B2 | 0.02 max | 1.0 max | 0.1 max | 0.03 max | 1.0 max | Bal | 1.0 max | 2.0 max | 26 – 30 | 0.04 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Hastelloy C276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
| Hastelloy C22 | 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000 , MPa – 690 | Psi – 45000 , MPa – 310 | 45 % |
| Hastelloy B2 | 9.2 g/cm3 | 1370 °C (2500 ºF ) | Psi – 1,10,000 , MPa – 760 | Psi – 51000 , MPa – 350 | 40 % |
| STANDARD | UNS | WNR. | JIS | GOST | EN | OR |
|---|---|---|---|---|---|---|
| Hastelloy C276 | N10276 | 2.4819 | NW 0276 | ХН65МВУ | NiMo16Cr15W | ЭП760 |
| Hastelloy C22 | N06022 | 2.4602 | NW 6022 | – | NiCr21Mo14W | – |
| Hastelloy B2 | N10665 | 2.4617 | – | – | – | – |
Yes, Hastelloy bright bars can undergo heat treatment to improve their strength and hardness. That said, the heat treatment process must be carefully managed to preserve their corrosion resistance.
To maintain the quality of Hastelloy bright bars, obtain them from trustworthy suppliers who provide certification for material composition and mechanical properties. Routine inspection and testing, including hardness and corrosion resistance evaluations, are equally important.
Yes, we supply Hastelloy Bright Bars in both standard and customized sizes and finishes to satisfy your particular project needs. For further information, email us at sales@alsummanmetals.ae
These Hastelloy Bright Bars are extensively used across industries requiring materials that combine strong corrosion resistance with accurate surface finishes. They work perfectly for building pumps, valves, heat exchangers, chemical reactors, and piping systems within chemical processing plants. Beyond that, these bars are also used in marine, offshore, and aerospace components thanks to their capacity to endure strong acids, chlorides, and oxidizing agents. Offering great weldability, formability, and lasting durability, Hastelloy Bright Bars provide reliable performance and stand as the preferred option for demanding industrial and engineering applications.
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
