Al Summan Metals, a well-regarded manufacturer and supplier based in Dubai, UAE, has established a strong reputation for delivering high-quality nickel-based alloys, including Inconel 617 Forgings. By emphasizing quality, precision, and innovation, Al Summan Metals guarantees that its products comply with international benchmarks for strength, corrosion resistance, and heat tolerance. The company serves a wide range of industries, including aerospace, power generation, chemical processing, and petrochemicals. Well known for its dependability and outstanding metallurgical know-how, Al Summan Metals reliably supplies Inconel 617 Forgings that excel in extreme temperatures and demanding conditions across the world.
Inconel 617 Forgings consist mainly of nickel (44.5–55%), chromium (20–24%), cobalt (10–15%), and molybdenum (8–10%), together with small quantities of aluminum, titanium, and carbon. This sophisticated alloy delivers impressive mechanical characteristics, with a tensile strength between 750 and 1000 MPa and exceptional creep resistance at temperatures reaching as high as 1100°C. It merges strong oxidation resistance with superb metallurgical stability, guaranteeing reliable performance under both oxidizing and carburizing environments. Inconel 617 additionally provides excellent weldability and toughness, which makes it an ideal option for demanding, high-temperature engineering uses.
SpecificationsASTM B564 / ASME SB 564, AMS 5887
Flat bar blocksup to 27″ width and 15,000 lbs.
Cylinders and sleevesup to 50″ maximum O.D. and 65″ maximum length
Discs and hubsup to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged ringsup to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shaftsup to 144″ maximum length and 20,000 lbs.
| C | Mn | S | Si | Cr | Mo | Ni | Cu | Ti | Al | B | Co | Fe |
| 0.05-0.15 | 1.0 Max | 0.015 Max | 1.0 Max | 20.0-24.0 | 8.0-10.0 | 44.5 Min | 0.5 Max | 0.6 Max | 0.8-1.5 | 0.006 Max | 10.0-15.0 | 3.0 Max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
| STANDARD | UNS | WNR. |
| Alloy 617 | N06617 | 2.4663 |
Temperature regulation while forging Inconel 617 secures an ideal grain structure, boosting its strength, durability, and resistance to thermal creep. Careful temperature handling also guards against material flaws such as cracking or distortion, raising overall quality.
Inconel 617 forgings can show diminished ductility at colder temperatures, which restricts how easily they can be worked. On top of that, their intricate alloy makeup and production methods can make them expensive.
Inconel 617 forgings need routine examinations to identify indications of oxidation or wear, especially under high temperatures. Consistent cleaning and protective coatings can assist in preserving their performance within demanding, high-temperature settings.
Inconel 617 Forgings are widely applied in sectors demanding outstanding resistance to heat and corrosion. They serve as ideal components for gas turbines, combustion cans, transition ducts, heat exchangers, and industrial furnaces. Because the alloy withstands oxidation and carburization so well, it suits petrochemical processing equipment and power generation systems perfectly. Within aerospace, it is applied to engine and exhaust parts subjected to intense heat. Al Summan Metals’ Inconel 617 Forgings deliver assured durability, strength, and reliability, offering enduring performance even in the harshest thermal and mechanical conditions.
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
