Al Summan Metals, based in Dubai, UAE, has established a strong reputation as a trustworthy manufacturer and supplier of premium **Inconel 600 Forgings**. Recognized for their accuracy and toughness, Al Summan Metals follows international standards, creating nickel-chromium alloy forgings capable of enduring extreme temperatures and severe corrosive conditions. Inconel 600, a nickel-chromium alloy, is valued for its outstanding resistance to oxidation, notable strength under high temperatures, and capacity to withstand corrosion in both acidic and alkaline environments. Owing to sophisticated forging methods and stringent quality control, Al Summan Metals ensures that its Inconel 600 Forgings provide reliable, durable, and high-performance solutions for sectors such as aerospace, chemical processing, power generation, and marine applications.
Inconel 600 Forgings consist mainly of nickel (a minimum of 72%) and chromium (14–17%), together with small quantities of iron, manganese, silicon, and additional elements. This distinctive makeup provides them with remarkable mechanical strength, excellent resistance to oxidation and carburization under high temperatures, and superior defense against general corrosion and stress-corrosion cracking. Mechanically speaking, these forgings feature a tensile strength between 515 and 760 MPa, a yield strength of 205 to 275 MPa, and solid elongation, which makes them ideal for high-temperature, high-stress uses.
SpecificationsASTM B564 / ASME SB564, AMS 5766
Flat bar blocksup to 27″ width and 15,000 lbs.
Cylinders and sleevesup to 50″ maximum O.D. and 65″ maximum length
Discs and hubsup to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged ringsup to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shaftsup to 144″ maximum length and 20,000 lbs.
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015 max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.47 g/cm3 | 1413 °C (2580 °F) | 655 MPa, 95000 psi | 310 MPa, 45000 psi | 45 % |
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST | OR |
| Alloy 600 | N06600 | 2.4816 | NC15FE11M | NiCr15Fe | NCF 600 | NA 13 | МНЖМц 28-2,5-1,5 | ЭИ868 |
El proceso de forjado del Inconel 600 suele durar varias horas, según la complejidad y el tamaño del componente. Espera — el texto está en inglés y contiene etiquetas HTML que debo conservar. Debo reescribir en inglés. Forging Inconel 600 generally requires several hours, varying with the size and complexity of the part. The heating, shaping, and cooling stages are all closely regulated to achieve the intended mechanical properties.
Post-forging procedures for Inconel 600 generally involve heat treatment to alleviate stresses and improve mechanical characteristics. Further steps such as machining, surface finishing, and inspection may likewise be necessary to satisfy particular application requirements.
Thanks to their outstanding resistance to corrosion and oxidation, Inconel 600 forgings need very little upkeep. To guarantee lasting performance in harsh conditions, it is advisable to inspect them regularly for indications of wear, cracking, or heat-related damage.
Inconel 600 Forgings are utilized across a range of industries that require protection against heat, corrosion, and chemical attacks. They are especially suitable for furnace components, heat exchangers, valves, nuclear reactors, turbine blades, and piping systems in chemical and petrochemical plants. In addition, they are extensively employed in the aerospace, marine, and power generation sectors where durability, high-temperature performance, and corrosion resistance are crucial. Thanks to their exceptional mechanical properties and reliability, Inconel 600 Forgings are the preferred option for demanding industrial and engineering applications.
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
